Description
Yoshitaki separator model DS-1 is a Japanese evacuation separator that is used for vapor and air fluids
The maximum pressure of this Yoshitaki separator is 2.0 Mpa and its maximum working temperature is 220 degrees
The body material of this Yoshitaki separator is made of cast iron and its frame material is made of hammered cast iron
The connection type of this separator is flange type
The end connection of this Yoshitaki separator is JIS 10KFF/16KFF/20KFF flanged, EN PN16/25 flanged, ASME Class 150/300 flanged.
The flow rate in this Yoshitake steam separator is 30 meters per second and air is 15 meters per second or less
This Yoshitake separator can be ordered in sizes A15, A20, A32, A40, A50
Important points in using Yoshitake separators
Using a higher flow rate will lead to separator failure
Keep the flow rate below the specified level
In advance, check the medium flow direction, inlet and outlet of Yoshitaki separators and install the separator correctly
When using Yoshitake DS-1 separators, it is recommended to replace the gasket every two years
Performance of Yoshitake separators
Drainage (condensation) in steam and air lines leads to reduced thermal efficiency, water hammer, corrosion of devices, valves, pipelines and many other problems
Yoshitake separator model DS-1 can effectively separate condensate from steam and air through the centrifugal force created by the passage configuration
In normal conditions, it is recommended to use a separator with the same diameter as the pipe for steam and compressed air systems
- Advantages of the Yoshitake DS-1 separator
- High efficiency of condensate separation
- Very low pressure drop
- Easy troubleshooting due to the use of few parts in the construction
Kiasanat is a supplier of Yoshitake separators, Spirax Sarco separators, etc
